Used Plastic Injection Molding Machine
Specification
| | | | GS68V |
| |
| A | B | C |
| INJECTION UNIT | Screw Diameter | mm | 26 | 30 | 34 |
| Screw L/D Ratio | L/D | 24.2 | 21 | 19.5 |
| Shot Size(Theoretical) | cm3 | 66 | 88 | 113 |
| Injection Weight | g | 60 | 80 | 103 |
| Injection Rate | g/s | 60 | 80 | 103 |
| Plasticizing Capacity | g/s | 6.3 | 8.4 | 10.3 |
| Injection Pressure | Mpa | 236 | 177 | 138 |
| Screw Speed | rpm | 0-260 |
| CLAMPING UNIT | Clamp Tonnage | KN | 600 |
| Toggle Stroke | mm | 270 |
| Space Between Tie Bars | mm | 310*310 |
| Max.Mould Height | mm | 330 |
| Min.Mould Height | mm | 120 |
| Ejector Stroke | mm | 70 |
| Ejector Tonnage | KN | 22 |
| Ejector Number | piece | 1 |
| OTHERS | Max.Pump Pressure | Mpa | 16 |
| Pump motor Power | KW | 7.5 |
| Heater Power | KW | 5.1 |
| Hopper Capacity | Kg | 25 |
| Oil Tank Capacity | L | 180 |
| Machine Dimension(L*W*H) | m | 3.77*1.11*1.76 |
| Machine Weight | t | 2.5 |
Used Plastic Injection Molding Machine
* Screw of big length to diameter ratio, uniform plastication and high plasticizing capability
* Multi Step adjustment of injection speed or pressure
* Back pressure control of molten plastic
* Double toggle mold closing system with a large force magnification ratio and a large stroke ratio
* Very good speed characteristic of high speed mold closing and low pressure mold protection
* Various kinds of hydraulic ejectors
* Double proportional, load sensitive hydraulic circuit
* For big sizes of machines there are several oil pumps in a group, use proportional valve to compensate the difference of pressure or flow between pumps
* Triple interlock of mechanic, electric and hydraulic devices
* Hydraulic knockout core device and rotary mold-parting the work piece device
* Using the computer, electric and hydraulic elements of famous brands in the world
FAQ:
1) How can I place order?
A: You can contact us by email about your order details, or place order on line.
2) How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank) and Paypal, Western Union are the most usual ways we are using.
3) What’s the order procedure?
A: First we discuss order details, production details by email or TM. Then we issue you an PI for your confirmation. You will be requested to do pr -epaid full payment or deposit before we go into production. After we get the deposit, we start to process the order. We usually need 7-15days if we don’t have the items in stock. Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.
4)How do you take care when your clients received defective products?
A: replacement. If there are some defective items, we usually credit to our customer or replace in next shipment.
5)How do you check all the goods in the production line?
A: We have spot inspection and finished product inspection. We check the goods when they go into next step production procedure.
